Axor Microspeed Plus Series - 5.1 Adjustment components

46
Service Manual
Plus
MICROSPEED
RENC
GAIN
RIP
RKV
RCA
RDT
RIN
RA
RAMP
5.1 Adjustement components
Droop compensation for internal motor resistance
(RI);Chapter 5.4 .
Nominal drive current resistor; Chapter 5.6
Armature Feedback resistor. It permit adaptament
at the costant motor tension. (See chapter 5.4)
Peak drive current resistor ; Chapter 5.6
Changes static gain in the velocity loop. Open
Solder bridge S6 and insert R GAIN if a change is
required. Consult factory for the correct value.
Resistor value that form the proportional/integral
network of the velocity Loop gain.
Standard values are 100 Kohm, there are disabled
by opening Solder bridge S5.
Adjustments
If we insert this resistance, we adapt KE
tachogenerator costant with input amplifier costant.
If the KE costant is small, we can bridge this
resistance (See chapter 5.3)
It gives ACC/DEC time. (See chapter 5.7)
If we insert this resistance, we adapt Impuls
Encoder costant with input amplifier costant. (Op-
tional See chapter 7.1)
