Axor Microspeed Plus Series - 1.2 Technical Data

8
Service Manual
Plus
MICROSPEED
1.2 Technical Data
MICROSPEED PLUS VOLTAGE
22Khz
32°-104°F (0°+40°C)
12°-158°F (-10°+70°C)
+/-5uV Degree F
+/-10Vdc
+/-7Vdc = (PK. curr.)
+5/+12Vdc ( 220 mA Max)
+/-10Vdc ( 4mA Max.)
250Khz Max.
2.5Khz
26.45 oz (750 gr.)
44.1 oz (1250 gr.)
10/95% non-condensing
--PWM frequency
--Operating Temperature
--Storage Temperature
--Drift
--Analog inputs
--Current Monitor (Imot)
--Encoder and Hall Signal
Power Supply (+V Optional)
--Auxiliary power supply
--Encoder Max.Freq. (Optional)
-- Band Width
--Weight Microb plus
--Weight Microb plus w/booster
--Humidity
TECHNICAL DATA CHARACTERISTICS
Size I nom. (A) I peak(A)
MICROSPEED PLUS CURRENT SIZES
1/2 +/-1 +/-2
2.5/5 +/- 2.5 +/- 5
6/12 +/- 8 +/- 16
10/20 +/- 10 +/- 20
14/28** +/- 14 +/- 28
20/40** +/- 20 +/- 40
* Minimum and maximum voltage. Tipical voltage are: 60Vdc,
140Vdc and 200Vdc.
Note a) The Microspeed plus 60 is produced only in sizes 14/28 e
20/40.
General Description
Microspeed 60 20 - 80 Vdc* Note a)
Microspeed 140 40 - 180 Vdc*
Microspeed 200 60 - 270 Vdc*
