Axor Microspeed Plus Series - 1.7 Signal inputs and outputs (continued)

Axor Microspeed Plus Series
64 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
15
Service Manual
Plus
MICROSPEED
3 GND
5 -10V(OUT)
6 ENABLE(IN)
4 +10V(OUT)
9 +DT(IN)
8 -REF(IN)
7 +REF(IN)
General Description
C) Current Reference (Torque Input):
S8 open S9 closed.
Range: +/- 10V, which corresponds to the drives peak current
output.
In this mode the velocity loop is automatically disabled .
Continued
Drive Common Ground. Corisponds to power supply's nega-
tive -AT input.
Power Supply +10Vdc 4mA Max.
Power Supply -10Vdc 4mA Max.
Drive Enable. Range +8Vdc to +24Vdc.
Reference Positive differential input. (Velocity command)
Reference Negative differential input. (Velocity command)
PositiveTacho input + (Connect to internal GND)
Negative Tacho input -
10 -DT(IN)
