31
Service Manual
Plus
MICROSPEED
Description:
It is important that the drive's ground connections are as short as
possible and no longer than 8 inches (20 cm). The figure shows
the connection using terminals fixed to the drive's base (bottom).
This connection also reduces disturbances in the net.
The Motor ground cable has to be external (not inserted in a
multipolar cable) with minimun section 1.5 mmq (0,059 square
inch).
Drive power and signal cables must be shielded. The cable
shields must be connected to the body of the motor.
Shelded cable is not required for the motor power cable, the +M
and -M cables should be twisted together.
On the follwoing page you'll find additional installation instructions
in respect to EMC requirements.
Installation
