49
Service Manual
Plus
MICROSPEED
S8 Normally open. (See chapter 3.8, 3.9, 3.9a)
S9 Normally closed. (See chapter 3.8, 3.9, 3.9a)
S10 Normally closed. (If open predisposes input function
+/-LM SW). Chapter 3.10
S11 Normally open.If closed enables Encoder Feedback. See
chapter 7.1
S12 Normally closed. If open you disable a internal allarm for
missing tachogenerator or Encoder.
S13 Normally closed. (Power supply on terminal +Vs=5Vdc.
If open configure +V=+12Vdc).
Only for Optional Encoder.
S14 -S15 Normally open.If closed you insert for each encoder
input a pull-up resistor of 3.3 Kohm to internal +14V.
Only for Optional Encoder.
S16- S17 Normally open.If closed you insert for PWM and
DIR input a pull-up resistor of 3.3 Kohm to internal +14V.
Note: Closed only for Pwm+Dir Optional.
Adjustments
NOTE: Further along in the manual all desired speed feedback are
highlighted the soldering points to close.
