Azbil SDC15 User Manual

1-2
■ Model selection table
The following shows the model selection table of this unit:
Chapter 1. OVERVIEW
Basic
Mounting
Control
PV input
Power
Option
Additional
Specifications
model No. output supply treatment
C15
T Panel mount type
(Note 1) S Socket mount type
Control output 1 Control output 2
(Note 2) R0 Relay contact output NO Relay contact output NC
V0 Voltage pulse output None
(for SSR drive)
(Note 3) VC Voltage pulse output Current output
(for SSR drive)
(Note 3) VV Voltage pulse output Voltage pulse output
(for SSR drive) (for SSR drive)
C0 Current output None
(Note 3) CC Current output Current output
T Thermocouple input
(K, J, E, T, R, S, B, N, PLII, Wre5-26, DIN U, DIN L)
R RTD input (Pt100/JPt100)
L DC voltage/DC current input (0 to 1Vdc, 1 to 5Vdc,
0 to 5Vdc, 0 to 10Vdc, 0 to 20mAdc, 4 to 20mAdc)
A AC Model (100 to 240Vac)
D DC Model (24Vac / 24 to 48Vdc)
00 None
01 Event relay output: 3 points
(Note 3,4) 02 Event relay output: 3 points
Current transformer input: 2 points
Digital input: 2 points
(Note 3,4) 03 Event relay output: 3 points
Current transformer input: 2 points
RS-485 communication
(Note 5) 04 Event relay output: 2 points
(independent contact)
(Note 3,4,5) 05 Event relay output: 2 points
(independent contact)
Current transformer input: 2 points
Digital input: 2 points
(Note 3,4,5) 06 Event relay output: 2 points
(independent contact)
Current transformer input: 2 points
RS-485 communication
00 No additional processing
D0 Inspection Certificate provided
Y0 Complying with the traceability certification
Note 1. Socket sold separately
Note 2. Only 1a contact is applicable for C15S
Note 3. Can not be selected for the C15S
Note 4. Current transformer sold separately
Note 5. Can not be selected for DC Model
