Azbil SDC15 User Manual

● PV input range table (Thermocouple) ● PV input range table (RTD)
*1. The accuracy of a B thermocouple is ±5%FS for a
range of 260˚C or less, ±1%FS for 260 to 800˚C.
The indicated low limit for a B thermocouple is 20˚C.
However, if ROM version 1 of the instrument
information bank (Id02) is prior to 2.04, the value is
-180˚C.
*2. PL II thermocouple is a range, which has been added
to the units manufactured from July, 2003.
*3. The PV range display for thermocouple with a decimal
point is available for ROM version 2.26 and later.
● PV input range table (DC voltage/DC current)
Handling Precautions
• When the C01 PV input range number is set, the decimal point position
and range are initially set automatically as shown in the tables. For
details on the decimal point, refer to;
SDC15 Single Loop Controller User's Manual for Installation &
Configuration CP-SP-1148E.
• Make sure to set the correct number in setup display C01, according to
the type and range of the sensor used. If the setting is wrong, problems
such as large temperature errors in the output may occur.
• For details about the accuracy of each PV range type, refer to;
Chapter 11, SPECIFICATIONS (on page 11-1).
5-3
Chapter 5. SETTINGS BEFORE STARTING OPERATION
C01 Sensor Range Range C04 C04 C04 initial value
set value type (Celsius) (Fahrenheit) display range when C01 settings
1K-200 to +1200˚C -300 to + 2200˚F ---- (Not setting) (No decimal point)
2K 0 to 1200˚C 0 to 2200˚F ---- (Not setting) (No decimal point)
3K0.0 to 800.0˚C 0 to 1500˚F ❍ 0 to 1 0
4K0.0 to 600.0˚C 0 to 1100˚F ❍ 0 to 1 0
5K0.0 to 400.0˚C 0 to 700˚F ❍ 0 to 1 0
6K-200.0 to +400.0˚C -300 to + 700˚F ❍ 0 to 1 0
9J0.0 to 800.0˚C 0 to 1500˚F ❍ 0 to 1 0
10 J 0.0 to 600.0˚C 0 to 1100˚F ❍ 0 to 1 0
11 J -200.0 to +400.0˚C -300 to + 700˚F ❍ 0 to 1 0
13 E 0.0 to 600.0˚C 0 to 1100˚F ❍ 0 to 1 0
14 T -200.0 to +400.0˚C -300 to + 700˚F ❍ 0 to 1 0
15 R 0 to 1600˚C 0 to 3000˚F ---- (Not setting) (No decimal point)
16 S 0 to 1600˚C 0 to 3000˚F ---- (Not setting) (No decimal point)
17 B 0 to 1800˚C 0 to 3300˚F ---- (Not setting) (No decimal point)
18 N 0 to 1300˚C 0 to 2300˚F ---- (Not setting) (No decimal point)
19 PL II 0 to 1300˚C 0 to 2300˚F ---- (Not setting) (No decimal point)
20 WRe5-26 0 to 1400˚C 0 to 2400˚F ---- (Not setting) (No decimal point)
21 WRe5-26
0 to 2300˚C 0 to 4200˚F
---- (Not setting) (No decimal point)
24 DIN U -200.0 to +400.0˚C -300 to + 700˚F ❍ 0 to 1 0
25 DIN L -100.0 to +800.0˚C -150 to + 1500˚F ❍ 0 to 1 0
C01 Sensor type Range (C05, C06) C04 C04 C04 initial value
set value display range when C01 settings
84 0 to 1V • Scaling range is -1999 to +9999. ❍ 0 to 3 No change
86 1 to 5V • When C01 is changed, the range (C05, C06) ❍ 0 to 3 No change
87 0 to 5V defaults to 0 to 1000. ❍ 0 to 3 No change
88 0 to 10V ❍ 0 to 3 No change
89 0 to 20mA ❍ 0 to 3 No change
90 4 to 20mA
❍ 0 to 3 No change
C01 Sensor Range Range C04 C04 C04 initial value
set value type (Celsius) (Fahrenheit) display range when C01 settings
41 Pt100 -200.0 to +500.0˚C -300 to + 900˚F ---- (Not setting) (No decimal point)
42 JPt100 -200.0 to +500.0˚C -300 to + 900˚F ---- (Not setting) (No decimal point)
43 Pt100 -200.0 to +200.0˚C -300 to + 400˚F ---- (Not setting) (No decimal point)
44 JPt100 -200.0 to +200.0˚C -300 to + 400˚F ---- (Not setting) (No decimal point)
45 Pt100 -100.0 to +300.0˚C -150 to + 500˚F ---- (Not setting) (No decimal point)
46 JPt100 -100.0 to +300.0˚C -150 to + 500˚F ---- (Not setting) (No decimal point)
51 Pt100 -50.0 to +200.0˚C -50 to + 400˚F ❍ 0 to 1 1
52 JPt100 -50.0 to +200.0˚C -50 to + 400˚F ❍ 0 to 1 1
53 Pt100 -50.0 to +100.0˚C -50 to + 200˚F ❍ 0 to 1 1
54 JPt100 -50.0 to +100.0˚C -50 to + 200˚F ❍ 0 to 1 1
63 Pt100 0.0 to 200.0˚C 0 to + 400˚F ❍ 0 to 1 1
64 JPt100 0.0 to 200.0˚C 0 to + 400˚F ❍ 0 to 1 1
67 Pt100 0.0 to 500.0˚C 0 to + 900˚F ---- (Not setting) (No decimal point)
68 JPt100 0.0 to 500.0˚C 0 to + 900˚F
---- (Not setting) (No decimal point)
