Azbil SDC15 User Manual

The Role of This Manual
v
Five different manuals in total are available for the SDC15 Single Loop Controller (hereafter referred to as
"this unit"). Read appropriate manuals according to your requirements. If you do not have your required manual,
contact the azbil Group or its dealer. Additionally, you can download necessary manuals from
"http://www.azbil.com".
The user level of this unit can be selected from three levels, "Simple configuration", "Standard configuration", and
"High function configuration". This manual describes the functions you can set up only with "Simple
configuration". If more advanced application is needed, refer to SDC15 Single Loop Controller User's Manual for
Installation & Configuration (CP-SP-1148E).
User’s Manual
WARNING
WARNING
CAUTION
CAUTION
SDC15 Single Loop Controller User's Manual for Basic Operation
Manual No. CP-SP-1147E
This manual. This manual is optional (sold separately). The manual
describes the functions you can set up only with "Simple configuration".
Personnel in charge of design, manufacture, operation, and/or
maintenance of a system using this unit must thoroughly read this manual.
This manual describes the installation, wiring, major functions and settings,
operating procedures, troubleshooting, and detailed specifications.
SDC15 Single Loop Controller User's Manual for Installation
Manual No. CP-UM-5287E
This manual is supplied with the product. Personnel in charge of design
and/or manufacture of a system using this unit must thoroughly read this
manual. This manual describes the safety precautions, installation, wiring,
and primary specifications. For further information about operation, refer to
other manuals, Basic Operation and/or Installation & Configuration.
SDC15 Single Loop Controller User's Manual for Installation &
Configuration Manual No. CP-SP-1148E
This manual is optional (sold separately). The manual describes the
hardware and all functions of this unit. Personnel in charge of design,
manufacture, operation, and/or maintenance of a system using this unit
and those in charge of communication software of a system using the
communication functions of this unit must thoroughly read this manual.
This manual also describes the installation, wiring, connections for
communication, all functions and settings of this unit, operating procedures,
communication with host station, such as personal computer,
communication addresses, troubleshooting, and detailed specifications.
SLP-C35 Smart Loader Package for SDC15/25/26/35/36 Single Loop
Controller User's Manual Manual No. CP-UM-5290E
This manual is supplied with the Smart Loader Package. The manual
describes the software used to make various settings for SDC15/25/26/35/
36 using a personal computer. Personnel in charge of design or setting of
a system using SDC15/25/26/35/36 must thoroughly read this manual. The
manual describes installation of the software into a personal computer,
operation of the personal computer, various functions, and setup
procedures.
CP-SP-1213E
SDC15 Quick Reference Guide
SDC15 Quick Reference Guide Manual No. CP-UM-1213E
For those using the SDC15 for the first time or for operators on the work
site, this guide serves as a reference when setting or modifying
parameters. Key operations, menu flowcharts and parameter settings are
presented with color illustrations.
