Programming Page 16/44
MID_M2000_BA_02_1004
Meter Setup
Pipe Diameter
This figure is used for setting pipe’s diameter (size). Several sizes DN
6 to DN 2000 as well as specific sizes in [mm] can be set.
Note: Pipe diameter is set at the factory. Changes of size have an
impact on meter’s accuracy.
Detector Factor
This parameter is set at the factory. This factor compensates for
accuracy error as a result of the installed detector. If accuracy
adjustment of the meter is required, please refer to the scale factor.
In the event the amplifier is replaced, this parameter must be
reprogrammed with the original detector factor.
Detector Offset
This parameter is set at the factory. This factor compensates for
accuracy error as a result of the installed detector. If accuracy
adjustment of the meter is required, please refer to the scale factor.
5.2.2 Measurement
Flow Units
Flow Units let you select among the Flow Units mentioned below. Flow
units are automatically converted into the selected unit.
Unit Unit
LPS Liter/Second GPM Gallons/Min.
LPM Liter/Minute GPH Gallons/Hour
LPH Litre/Hour MGD MegaGallon/Da
M3S Cubic meters/Sec. IGS UKG/Sec.
M3M Cubic meters/Min. IGM UKG/Min.
M3H Cubic IGH UKG/Hour
F3S Cubic Feet/Sec. LbM Pound/Min.
F3M Cubic Feet/Min. OPM Ounce/Min
F3H Cubic Feet/Hour. BPM Barrel/Min
GPS Gallons/Sec. -- --
