Programming Page 13/44
MID_M2000_BA_02_1004
5. Programming
Programming is accomplished by using the three functional buttons ▲,► and E.
You can move from the measuring mode to the programming mode by pressing twice the
button E. While first pressing this button, you activate the backlight and while pressing it for a
second time, you get into the programming menu.
The cursor → on the left side of the display is moved upward and downward with the buttons
▲/ ►. The menu manager or selection from a list is marked with the cursor and
acknowledged by pressing the button E.
To enter a parameter, the first number is marked with an underline 0
. By pressing the buttons
+ / -, you can increment or decrement them. As soon as the requested number has been
selected, you can acknowledge it by pressing the button E. After having entered the last
number, the value is stored by pressing the button E or press the button + in order to edit the
value again.
You get access to the individual menus through three programmable access levels:
Administrator, service and user level.
Access rights of the individual menu items is shown in the following with three symbols:
Administrator Service User
For programming the access levels, see the chapter “passwords”.
No passwords were set at the factory.
5.1 Quick setup
The M2000 amplifier provides you with a quick setup utility that allows you to quickly
set most of the important parameters like flow units, totalizer units, full scale flow and
low flow cutoff settings.
Quick Setup
Flow Units
Flow units let you select among the flow units mentioned below. Flow
units are automatically converted into the selected unit.
Unit Unit
LPS Liter/Second GPM Gallons/Min.
LPM Liter/Minute GPH Gallons/Hour
LPH Liter/Hour MGD MegaGallon/Da
M3S Cubic meters/Sec. IGS UKG/Sec.
M3M Cubic meters/Min. IGM UKG/Min.
M3H Cubic IGH UKG/Hour
F3S Cubic Feet/Sec. LbM Pound/Min.
F3M Cubic Feet/Min. OPM Ounce/Min.
F3H Cubic Feet/Hour. BPM Barrel/Min.
GPS Gallons/Sec. -- --
