Programming Page 27/44
MID_M2000_BA_02_1004
5.2.6 Advanced
Unit Multiplier
This function lets you define totalizers’ formatting. You can select
among the following formats:
Formatting is normally [Aus/off]. With this function, the best possible
resolution is automatically chosen.
Backlight Control
You can set the meter’s backlight to “Aways On“, “Always Off“ or
“Time (1 min)”.
When set to “Time (1 min)“, the backlight will automatically turn off
after one minute of inactivity (no buttons pressed). Pressing one of
three buttons will turn the backlight on.
Note: A longer operation with the option „always on“ can have a
negative effect on LCD’s life.
Analog Calibrate
Analog calibrate lets you configure the current output.
Note: The analog output was already set at the factory. Normally an
additional calibration is not necessary. In the event that you wish to
adapt the output to your external system, see “corrective factor“.
Corrective
Factor
The analog output was already set at the factory to
exactly 4.00 mA (zero) und 20.00 mA (margin). In
the event that your external system shows another
parameter, you can simply correct the offset via this
function.
First select “Set 4 mA Offset“ and enter another
parameter for zero. In the event that your system
shows 3.70 mA instead of 4.00 mA, enter the
difference of -00.30 mA as corrective factor. The
same applies to the item “Set 20 mA Offset“ in order
to correct the margin.
Format
0.0001 1
0.001 10
0.01 100
0.1 1000
