Badger Meter ModMAG M2000 Installation And Operation Manual

Programming Page 26/44
MID_M2000_BA_02_1004
5.2.5 Communications
Data Bits The following data bits are supported:
• 8 bits
• 7 bits
• 5 bits
Default settting is [8 bits]
Stop Bits The following stop bits are supported:
• 1 Stop Bit
• 2 Stop Bits
Default setting is [1 Stop Bit]
Port B
This port cannot be configured.
Diagnostics
Port A
This function allows diagnostics in cases where the port Modbus RTU
is used.
Counter Description
Pkts
Processed
Number of packets processed by meter.
Broadcast
Pkts
Number of broadcast packets (Address = 0)
p
rocessed b
y
meter.
CRC Errors Number of received packets with CRC error;
packet is discarded.
Pkts Rcvd
Number of packets received with an address of
the confi
g
ured
p
ort address
Pkts Sent No. of packets transmitted in response to a received
Parity
Errors
Number of characters with parity errors;
packet is discarded.
Framing
Errors
Number of characters with framing error
(e.g. missing stop bit – synchronization problem);
packet is discarded.
Overrun
Errors
Number of received characters that were not
processed due to degradation of system
performance.
Break
Detects
Number of breaks during transmission.
