Badger Meter ModMAG M2000 Installation And Operation Manual

Programming Page 22/44
MID_M2000_BA_02_1004
Inputs and Outputs
Digital Outputs Functional
selection
The following functions can be selected for the
outputs 1 to 4:
Inactive
means digital output is switched off.
Forward pulse generates pulses during forward flow
conditions.
Reverse pulse
generates pulses during reverse flow
conditions.
AMR (50 ms)
serves for an adaptation to the
“Automatic Meter Reading“ system.
Frequency output
generates pulses correlated to the
absolute value of the flow rate.
Flow set point
provides indication when flow rate
exceeds thresholds defined by flow set points.
Empty pipe alarm
provides indication when pipe is
empty.
Flow direction
provides indication on current flow
direction
Preset output
provides indication when preset batch
amount has been realized.
Error alarm
provides indication when meter has error
condition.
24 VDC Suppy
provides constant 24 volts on output
(forces output type to normally open. The jumper JP1
or JP2 must be placed (active output).
Function Dig1 Dig2 Dig3 Dig4
Inactive X X X X
Forward pulse X X
Reverse pulse X X
AMR (50 ms) X
Frequency X
Flow set point X X X X
Empty pipe alarm X X X X
Flow direction X X X X
Preset output X X X X
Error alarm X X X X
24 VDC Supply X X

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
