Activating Endpoints
ORI-UM-00025-EN-19
ORION endpoint wires: Red = Power/Clock; Black = Ground; Green = Data
Endpoint
Label Encoder Connectivity
Endpoint Wire Colors
Red Black Green Reading Resolution
ADE
Badger Meter ADE, HR-E LCD or HR-E encoders,
or E-Series Ultrasonic Meter with High Res or
ADE output
Encoder Wire/Termination Colors
Red Black Green Up to seven (7) most signicant digits
RTR
Badger Meter RTR or E-Series Ultrasonic Meter with
RTR output
Red Black Green Up to seven (7) most signicant digits
UNIV* Elster/AMCo ScanCoder or Invision Green Black Red Up to seven (7) most signicant digits
UNIV*
Master Meter Octave Ultrasonic meter
(encoder output)
Red Black Green Up to seven (7) most signicant digits
UNIV* Metron Hawkeye Red Black Green Up to seven (7) most signicant digits
UNIV* Mueller Systems 420 Solid State Register (SSR) LCD Red Black Green Up to seven (7) most signicant digits
ARB-V*/**
Neptune ARB-V for connectivity to
ORION endpoint > serial number 80000000
Black Green Red Up to seven (7) most signicant digits
ARB-V*/**
Neptune ARB-V for connectivity to
ORION endpoint < serial number 79999999
Red Black Green Up to seven (7) most signicant digits
UNIV* Neptune ProRead or E-coder Black Green Red Up to seven (7) most signicant digits
UNIV* Sensus Electronic Register Encoder (ECR) or ICE Red Black Green Up to seven (7) most signicant digits
UNIV* Hersey Translator
Due to the customized, factory wire configurations of the Hersey Translator,
the terminal posts may not match the ORION endpoint wire colors. Please
contact Hersey for the terminal post wiring schematic of your encoders to
determine how the posts correspond to ORION endpoint wires.
OTE:N Competitive encoder output is determined by the encoder configuration.
*ORION Classic UNIV and ARB-V endpoints are compatible with the encoders/meters noted above with a manufacture date within 10 years of the current
date as long as the encoder is programmed into the three-wire output mode for AMR/AMI and has three wires connected to it. Encoder registers that are
currently in two-wire mode of operation require programming by the Utility, including registers that support auto two- or three-wire detection systems that
do not automatically switch to three-wire mode of operation once a compatible endpoint is connected for ORION connectivity.
**A separate ORION CE Universal endpoint is available for connectivity to the Neptune ARB-V encoder. Make sure the ORION Classic endpoint has “ARB-V” on
the harness label when wiring to an ARB-V encoder. Wiring differs depending on the serial number of the ORION endpoint you are connecting to the ARB-V
encoder, so make sure to verify wiring is correct per the above chart.
Installation Guidelines (Indoor, Outdoor, Pit)
Install the endpoint/encoder assembly according to these guidelines:
• Indoor/Outdoor Installation: Mount outside the building, or indoors in the floor joist, near an outside wall, and
away from large metal objects.
• Pit Installation: Mount through a NON-METAL pit lid—Recommended.
OTE:N Endpoints not properly installed may not be covered under warranty.
Endpoint Activation
See "Activating Endpoints" on page 11 for details of the process.
