BAFANG MAX Drive System User Manual

19
DEALER MANUAL MAX DRIVE SYSTEM
C
M6 nuts
1401080000101
Insert, from the right, special M6 nuts into the mounting holes in the bike frame and the drive unit.
D
M6 bolts
1401080000099
Insert, from the left, the M6 bolts into the bike frame so that they will come to contact with the nuts. Tighten bolts
onto nuts to the specified torque.
Tightening torque: 18 – 20 Nm
