BAFANG MAX Drive System User Manual

20
SYSTEM INSTALLATION
DEALER MANUAL MAX DRIVE SYSTEM
A
upper cover of the
connector box
B
connector box body
Open the connector box and get ready to link female connectors with male connectors.
Push the lower part of each of the male buckles on the connector box body (in the direction as show by the arrows in
the picture above) to release the female buckles on the upper cover. Push the upper cover in the direction of moving
towards Buckle 3 to fully open the upper cover.
