Figure 14: WLAN (2 of 2)
Every SSID can be configured independently. The example in Figure 15 and Figure 16 is for an SSID in the 2.4
GHz range. Refer to Table 7 for a description of each field.
Figure 15: Device Configuration (2.4 GHz SSID)
Figure 16: Interface Configuration (2.4 GHz SSID)
Table 7: SSID (2.4 GHz) Configuration
Item
Value
Description
Network Mode
802.11b/g
802.11b
802.11g
802.11g/n
802.11b/g/n
Wi-Fi mode selection
Channel
Channels 1~14 and auto
Wi-Fi frequency band
Bandwidth
20 MHz
40 MHz
Default: 40 MHz
Country Code
US
Default: None
