INTRODUCTION

REFERENCE DOCUMENTS

1 - 4 I-E96-409A

REFERENCE DOCUMENTS

Table 1-3 lists the documents referenced in this instruction.

NOMENCLATURE

Table 1-4 is a list of related hardware.

Table 1-3. Reference Documents

Document Number Document

I-E93-902-1 Digital Control Station (NDCS03)

I-E96-116 Digital Indicator Station (NDIS01)

I-E96-117 Analog Control Station (IISAC01)

I-E96-207 Controller Modules (IMCOM03/04)

I-E96-215 Quick Response Controller (IMQRC01)

I-E96-306 Control I/O Slave Module (IMCIS02)

I-E96-316 Quick Response Slave Module (IMQRS02)

I-E96-401 Multi-Function Controller Termination Module (NIMF01/02)

I-E96-412 Digital Logic Station Termination Module (NIDS01)

I-E96-413 Multi-Function Processor Termination Module (NIMP01/02)

I-E96-415 Remote Link Termination Module (NIRL03)

Table 1-4. Nomenclature

Nomenclature Hardware

NICS01 Controller/station termination module.

NKTU02 (PVC) and

NKTU12 (non-PVC)

Cable from NICS01 to IMCIS02, IMCOM03, IMCOM04, IMQRC01 and

IMQRS02 modules.

NKTM01 (Ribbon) Cable from NICS01 to IMCIS02, IMCOM03, IMCOM04, IMQRC01 and

IMQRS02 modules.

NKTD02 (PVC) and

NKTD12 (non-PVC)

Cable from NICS01 to NDCS03, NDIS01 or IISAC01 stations (no analog output

bypass capability).

Bailey Raw Material P/N

R2041-0397

Serial link wire.

258436_1 Cable retaining kit used when at least one round cable is connected to the TMU.

6634408_2 Ribbon cable from J1 connector of NICS01 module to J1 connector of NIDS01

module.
