Bailey NICS01 - Switch S4 Settings (Modes; Switch S4 Settings (Module Address; Jumper J1, J2 and J3 Settings

IMCOM03 AND IMCOM04 CONTROLLER MODULE CONFIGURATION
INTRODUCTION
B - 2 I-E96-409A
®
Table B-2. Switch S4 Settings (Modes)
Function
Switch Position
12345678
Normal mode:
Normal operation 00000000
NVRAM initialization 01000000
Configuration lockout 00100000
NOTE:
0 represents the CLOSED or ON side
of the switch. 1 represents the OPEN or OFF
side of the switch.
Table B-3. Switch S4 Settings (Module Address)
Address Example
Switch Position 4 5 6 7 8
Binary Value 16 8 4 2 1
0 00000
8 01000
16 10000
24 11000
31 11111
NOTE:
0 represents the CLOSED or ON side of the switch.
1 represents the OPEN or OFF side of the switch.
Table B-4. Jumper J1, J2 and J3 Settings
Jumper
Position
Digital Input
Type
1-2 24 VDC
2-3 125 VDC
