Bailey NICS01 - NICS01 Terminal Strip Assignments; Example Input Circuits

INSTALLATION
SETUP/PHYSICAL INSTALLATION
I-E96-409A 2 - 9
The NICS01 is ready for operation if:
1. The fuse is installed.
2. The dipswitches are configured for the types of inputs and
outputs desired.
3. All required cables are installed and verified.
4. Power is connected and applied to the ICS module.
Figure 2-6. NICS01 Terminal Strip Assignments
COMMON +24 VDC
1
11 1 1234
2
22 23
3
3
4
4
5 6 7 8 9 10 11121314 151617181920 21 232425262728293022
ANALOG INPUT ANALOG
OUTPUT
DIGITAL INPUT SERIAL
LINK
DIGITAL OUTPUT
T00135A
TERMINAL NUMBER
Figure 2-7. Example Input Circuits
TRANSMITTER
+
–
+
–
+
–
+
–
+
–
+
TRANSMITTER
EXTERNAL
+24 VDC
EXTERNAL COMMON
T00502A
VOLTAGE
SOURCE
SYSTEM POWERED
4TO20mA
EXTERNALLY POWERED
4TO20mA
SINGLE-ENDED VOLTAGE
1TO5VDC
DIFFERENTIAL VOLTAGE
1TO5VDC
