Baldor MintDrive User Manual

13
LN
Fuse
Connection
L
N
L1 L2
Earth
MintDrive
Circuit breaker and fuse not supplied.
For CE Compliance, see Appendix C.
Circuit
Breaker
L3
PE
L1 L2
Figure 5 - Circuit breaker and fuse, single phase, package size C
L1
Fuse
Connection
L
1
L
2
L1 L2
Earth
MintDrive
Circuit breaker and fuse not supplied.
For CE Compliance, see Appendix C.
Circuit
Breaker
L3
PE
L
3
L2 L3
L1 L2 L3
Figure 6 - Circuit breaker and fuse, three phase, package size C
Note: Metal conduit or shielded cable should be used. Connect conduits so the use of a Reactor
or RC Device does not interrupt EMI/RFI shielding. If local codes do not specify different
regulations, use the same gauge wire for Earth ground as is used for L and N.
Connect earth to the backplane of the enclosure.
