Baldor MintDrive User Manual

22
2.5 Feedback connections
Two feedback options are available; a commutating encoder or a resolver, both using connector X2.
Check with the catalog number (see page 2) to ensure you are wiring the correct feedback device.
Resolver based MintDrives provide a simulated encoder output signal available on connector X3 for
master/slave type applications. Encoder based MintDrives duplicate the encoder signals entering X2.
The following points must be observed when wiring the feedback device:
H The feedback device wiring must be separated from power wiring
H Parallel runs of the device wiring must be separated from power cables by at least 3” (76mm)
H Power wires must be crossed at right angles only
H To prevent contact with other conductors or grounds, ungrounded ends of shields must be insulated.
