Baldor MintDrive User Manual

80
6.1.2 Power
Mains and motor output
Unit 2.5A 5A 7.5A 10A 15A
Nominal input voltage (V
in
=230VAC) VAC 230
Minimum input voltage 220
Maximum input voltage 250
Nominal DC-Bus voltage VDC 320
Minimum DC-Bus v oltage 306
Maximum DC -Bus v oltage 350
Nominal input voltage (V
in
=115VAC) VAC 115
Minimum input voltage 97
Maximum input voltage 125
Nominal DC-Bus voltage VDC 160
Minimum DC-Bus v oltage 135
Maximum DC -Bus v oltage 176
Output voltage (line-line)
@VDC-Bus=320V
V
RMS
0 ~ 230
Nominal phase current (±10%) A
RMS
2.5 5.0 7.5 10 15
Peak phase current (±10%)
for 2.4s (+0.5s / - 0s)
A
RMS
5 10 15 20 30
Nominal output power kVA 1.01 2.17 2.99 4.33 6.51
Efficiency % >95
Output frequency Hz 0 ~ 500
Nominal switching frequency kHz 8.5
Optional 24V supply
Unit All models
Input voltage minimum
V
RIPPLE
= 1 0 % maximum
VDC 20
30
Input current maximum
@24VDC
A
RMS
1.6
Surge c urrent at power on
@24VDC for 100ms
A
RMS
4
