BTL6-E500-M_ _ _ _-E2/E28-KA_ _/KE_ _/LA_ _
Micropulse Transducer - Rod Style
english
8
Resolution
typical ± 7 µA,
with input filter 27 KHz
Sampling rate
nom. length < 1300 mm 1 kHz
nom. length > 1300 mm 0.5 kHz
Non-linearity:
nom. length < 500 mm < ±200 µm
nom. length > 500 mm < ±0.04 % FS
typ.±0.02 %FS
Temperature
coefficient typ. 25 µm/K
8.1 Dimensions, weights,
ambient conditions
Dimensions
➥➥
➥➥
➥ page 4
Weight approx. 2.0 kg/m
Housing Stainless steel 4404
Pressure tube Stainless steel 4571
BTL6...E2 BTL6...E28
nom. length < 1500 mm < 1016 mm
Diameter 10.2 mm 8 mm
Wall thickness 2 mm 0.9 mm
E-Moduls approx. 200 kN/mm²
Support ring PTFE
O-Ring NBR
Operating temp. -40 °C to 85 °C
Storage temp. max. 90 °C
8 Technical Data
Typical values at DC 24 V, room temperature and BTL6-E500-... with nominal length 500 mm and KA02. Ready to
use, full accuracy reached after warm-up phase. With magnet BTL-P-1013-4R, BTL-P-1014-2R, BTL-P-1012-4R or
BTL-P-0814-GR-PAF:
Humidity < 90 %, non-dewing
Protection rating IEC 60529 IP 67
when closed up
Shock loading 100 g/6 ms
per IEC 60068-2-27
1
Continuous shock 50 g/2 ms
per IEC 60068-2-29
1
Vibration 12 g, 10 to 2000 Hz
per IEC 60068-2-6
1
(take care to avoid natural
resonance of protective )
Pressure
BTL6...E2 up to 350 bar
BTL6...E28 up to 250 bar
when installed in a hydraulic
cylinder
1
Individual specifications as per Balluff
factory standard
8.2 Supply voltage (external)
Regulated supply
voltage DC 10 ... 30 V
Ripple
< 0.2 V
ss
Current draw typical 2 W
Inrush typical
(Sampling rate 1 KHz) < 80 mA
at 24 V DC
Overvoltage 36 V
Polarity reversal
protection max. 40 V
No. 853 589 -726 E • 00.000000 • Edition 0707; specifications subject to changes.
Emission tests:
RF Emission
EN 55011 Group 1, Class A+B
Noise immunity tests:
Static electricity (ESD)
EN 61000-4-2 Severity level 3
Electromagnetic fields (RFI)
EN 61000-4-3 Severity level 3
Fast transients (Burst)
EN 61000-4-4 Severity level 3
Surge
EN 61000-4-5 Severity level 2
Line-induced noise induced by
high-frequency fields
EN 61000-4-6 Severity level 3
Magnetic fields
EN 61000-4-8 Severity level 4
The CE Mark verifies
that our products meet
the requirements of
EC Directive
89/336/EEC (EMC Directive)
and the EMC Law. Testing in our
EMC Laboratory, which is accred-
ited by DATech for Testing Electro-
magnetic Compatibility, has con-
firmed that Balluff products meet
the EMC requirements of the fol-
lowing Generic Standards:
EN 61000-6-4 (emission)
EN 61000-6-2 (noise immunity)
8.3 Output signals
Position signal
BTL6-E 4 - 20 mA
Error signal
BTL6-E < 4 mA, typ. 3.6 mA
8.4 Overvoltage protection
Dielectric strength with
respect to housing
BTL6-...E2- 500 V DC
Compatibility tests (EMC Directi-
ve):
ISO 14982
Agricultural and Forestry
Machinery
ISO 13766
Earthmoving Machinery
ISO 7637-1/2/3
Highway Vehicles
EN 12895
Lift Trucks
EN 50121-3-2
Rail applications
ISO 11452-5 Electromagnetic
field HF, 200 V/m
Restrictions:
External protection measures must
be taken:
EN 150121-3-2:
(Burst 2kV per EN 61000-4-4):
ISO 7637-2 Pulse 5a
External buffering measures must
be taken:
Fluctuations and interruptions in
the supply
(EN 50155)
