Banner Q4X Series User Manual

Figure 15. Sample
Active
Sample
Inactive
(t)
Input
Signal
Hold
Measurement
Hold
Measurement
Measuring Period
Measuring Period
REMOTE
INPUT
(
Active Low shown)
Figure 16. Average
Average
(t)
Input
Signal
Measuring Period Measuring Period
Hold
Measurement
Hold
Measurement
Active
Inactive
REMOTE
INPUT
(
Active Low shown)
Figure 17. Maximum and Minimum
Active
Hold
Measurement
Hold
Measurement
Inactive
Maximum
Minimum
Measuring Period
(t)
Input
Signal
Hold
Measurement
REMOTE
INPUT
Measuring Period
(
Active Low shown)
Measuring Period
Figure 18. Range
Active
Inactive
Range
Measuring Period
(t)
Input
Signal
Min
Max
Min'
(Max'-Min')
(Max-Min)
Max'
REMOTE
INPUT
(
Active Low shown)
Measuring Period
Hold
Measurement
Hold
Measurement
Figure 19. Track Maximum and Track Minimum
Active
Inactive
TrackMax
TrackMin
(t)
Input
Signal
Hold
Measurement
Hold
Measurement
REMOTE
INPUT
Measuring Period Measuring Period
(Active Low shown)
3.1.10 Display View
Use this menu to select the display view. The default is normal.
• —Normal
•
—Inverted (rotated 180°)
• —Normal and the display enters sleep mode after 60 seconds
• —Inverted (rotated 180°) and the display enters sleep mode after 60 seconds
When the sensor is in sleep mode, the display wakes with the first button press.
3.1.11 Exit Setup Mode
Navigate to and press SELECT to exit Setup mode and return to Run mode.
3.1.12 Reset to Factory Defaults
Use this menu to restore the sensor to the factory default settings.
Select to return to the sensor menu without restoring the defaults. Select to apply the factory defaults and
return to Run mode.
Q4X Stainless Steel Analog Laser Sensor
www.bannerengineering.com - Tel: + 1 888 373 6767 15
