3 Sensor Programming
Program the sensor using the buttons on the sensor or the remote input (limited programming options).
In addition to programming the sensor, use the remote input to disable the buttons for security, preventing unauthorized or
accidental programming changes. See Locking and Unlocking the Sensor Buttons on p. 18 for more information.
3.1 Setup Mode
1. Access Setup mode and the sensor menu from Run mode by pressing and holding MODE for longer than 2 seconds.
2. Use and to navigate through the menu.
3. Press SELECT to select a menu option and access the submenus.
4. Use and to navigate through the submenus.
5.
Select a submenu option.
•
Press
SELECT
to select a submenu option and return to the top menu.
• Press and hold SELECT for longer than 2 seconds to select a submenu option and return immediately to Run
mode.
To exit Setup mode and return to Run mode, navigate to
and press SELECT.
Q4X Stainless Steel Analog Laser Sensor
8 www.bannerengineering.com - Tel: + 1 888 373 6767
