Excess Gain using a 90% White Card—600/610 mm Models
Table 8:
Excess Gain ( Excess Gain
3
)
Response
Speed (ms)
· at 25 mm (600 mm models)
· at 35 mm (610 mm models)
· at 100 mm (600 mm models)
· at 110 mm (610 mm models)
· at 300 mm (600 mm models)
· at 310 mm (610 mm models)
· at 600 mm (600 mm models)
· at 610 mm (610 mm models)
2 280 110 25 6
5 280 110 25 6
15 1000 (360) 400 (150) 80 (30) 20 (7)
25 2000 (1000) 800 (400) 160 (80) 40 (20)
50 4000 (2000) 1600 (800) 320 (160) 80 (40)
Environmental Rating
IEC IP67 per IEC60529
IEC IP68 per IEC60529
IP69K per DIN 40050-9
per DIN40050-9
Shock
MIL-STD-202G, Method 213B, Condition I (100G 6x along X, Y, and Z
axes, 18 shocks), with device operating
Vibration
MIL-STD-202G, Method 201A (Vibration: 10 Hz to 60 Hz, 0.06 inch (1.52
mm) double amplitude, 2 hours each along X, Y and Z axes), with device
operating
Storage Temperature
–25 °C to +75 °C (–13 °F to +167 °F)
Operating Conditions
35% to 95% relative humidity
Min. Ambient
Temp (°C)
Max. Ambient Temp (°C)
Vcc All Models
Q4X…U
(0–10V)
Q4X..I
(4–20 mA)*
12
–10 50
50
24 45
30 40
* For 4–20 mA models only: Max. Ambient Sensor Temp (°C) = 50 –
(Vcc – 12)/2
Required Overcurrent Protection
WARNING: Electrical connections must be
made by qualified personnel in accordance
with local and national electrical codes and
regulations.
Overcurrent protection is required to be provided by end product
application per the supplied table.
Overcurrent protection may be provided with external fusing or via
Current Limiting, Class 2 Power Supply.
Supply wiring leads < 24 AWG shall not be spliced.
For additional product support, go to www.bannerengineering.com.
Supply Wiring (AWG) Required Overcurrent Protection (Amps)
20 5.0
22 3.0
24 2.0
26 1.0
28 0.8
30 0.5
Certifications
Industrial
Control
Equipment
3TJJ
Class 2 power
UL Environmental Rating: Type 1
chemical compatibility certified
ECOLAB is a registered trademark of Ecolab USA Inc. All rights reserved.
3
• excess gain available in 15 ms response speed only
•
excess gain provides increased noise immunity
Q4X Stainless Steel Analog Laser Sensor
www.bannerengineering.com - Tel: + 1 888 373 6767 23
