Abbreviation Description
Input wire = remote teach function
Shift the Zero Reference Location after a TEACH
Slave
Span—analog window size
Response speed
TEACH process selection
Trigger setting for tracking maximum measurement value
Trigger setting for tracking minimum measurement value
Trigger
Trigger—Set the trigger type
Volt
Unlock/unlocked
Saturated signal (too much light)
Zero—select the zero reference location
Q4X Stainless Steel Analog Laser Sensor
30 www.bannerengineering.com - Tel: + 1 888 373 6767
