167R5911705 /02 Bragi
10.2.2 Projector address
About individual projector address
As more than one projector can be installed in a room, each projector should be separately addressable with
an RCU or with a computer using serial communication. Therefore each projector has its own address. The
factory default individual projector address is ‘0’.
When the address is set, the projector can be controlled with the RCU. Only addresses between 0 and 31 are
supported for the RCU.
Next to an individual projector address, each projector has also a broadcast address for group control.
How to change
1. In the main menu, select Settings → Communication → IR Control.
Image 10–4 Communication menu, IR control
The IR control menu is displayed.
2. Select the current projector address and enter a new address.
3. Select APPLY and click OK to apply the changes.
From now on the projector will only listen to this new address and to its broadcast address.
