33R5911705 /02 Bragi
3.2 Installation conditions
Environmental Conditions
Barco projectors are manufactured according to specific design standards, which also include
environmental conditions. Failing to follow the terms and conditions outlined in this chapter can
result in loss of product warranty
The table below summarize the physical environments in which the projector may be safely operated or
stored.
Environment
Ambient operating
temperature
Relative Humidity Storage condition
0 -1500m +10 to +40 °C 10 –80% RH –20 to +60 °C, 10 – 90 %
RH
1500 -3000m +10 to +35 °C 10 –80% RH –20 to +60 °C, 10 – 90 %
RH
Maximum Air Flow 400m
3
/hour 10 –80% RH Not Applicable
For PRC (People’s Republic of China) the certified altitude is specified on the product label.
Mains power requirement
Projector Power Requirement
Projectors, all in range 100 –240V. 60 –50 Hz.
To protect operating personnel, the National Electrical Manufacturers Association (NEMA) recommends that
the instrument panel and cabinet be grounded.
In no event shall this projector be operated without an adequate cabinet ground connection.
The AC supply must be installed by a qualified electrician in conformance to local codes. Hardware, wire sizes
and conduit types must comply with local codes.
Ventilation
To ensure that correct airflow is maintained, the projector must only operated when all the covers
are in place. The only exception is the front cover, see “Projector safe attachment points”.
The free space necessary between the air intake and exhaust are shown below.
Physical installation
