2. ClickShare Specifications
4
VGA display connector
5
HDMI connector
6
USB port
7
Power connection
Mechanical fix ture points
The mechanical fixture points are loc ated at the bottom of the B ase Unit
Antenna
Tw o antennas are included in the ClickShare box. To avoid dam age during transport, they a re not pre-mounted.
The antennas can rotate for a better wireless connection.
Usage of antennas other t han the ones provided with the unit are allowed within the res trictions on usage of other antennas defined
by local regu lations. B arco does not take responsibility for damage or disturbance of other devices that may be caused by using a
different antenna. The use of an active power amplifier is not allowed.
Antenna type : Dipole
Gain : Maximum 2dBi peak gain in 2.4GHz and 5Ghz band
Bottom layout of the Base Unit
The se rial number label with the applicable certific ation logos is s tuck a t t
he bottom of the Base Unit.
The serial numbe r label contains:
• the Barco logo
• the Barco part number
• the serial num ber
• the revision num ber
• the production date (week/year)
• markings for applicable standards (CE, CCC, UL, ...)
• markings for was te r egulation
• “Made in ...”
2.4 About the Button
Buttom
A Button toggles the sharing of the individual PC or MAC screen on the meeting screen.
Button layout
A Button consists of three ma in com ponents.
1 2 3
Image 2-4
Button layout
1
USB connector
2Button
3LEDring
Tabl e 2 - 6
R5900014 CLICKSHARE 16/09/2013 9
