3. Getting started
3. GETTING STARTED
Overview
• Environmental Condition Check
•BasicWorkflow
3.1 Environmental Condition Check
Environment condition c h eck
For installations in environments where the device is subject to excessive dust, then it is highly advisable and desirable to have t his
dust removed prior to it reaching the device clean air s upply. Devices or structures to extract or shield ex cessive dust w ell away
from the device are a prerequisite; if this is not a feasible solution then measures to r elocate the device to a clean air environment
should be considered.
It is the customer’s responsibility to ensure at all times that the device is protected from the harm ful effects of hostile airborne particles
in the environm ent of the device. The m anufacturer reserves the right to refuse repair if a d
evice has been subject to negligence,
abandon or improper use .
Ambient temperature conditions
Max. ambient temperature : +40°C or 104°F
Min. ambient temperature: +0°C or 32°F
Storage temperature: -10°C to +60°C (14°F to 140°F)
Humidity Conditions
Storage: 0 to 90% relative hum idity, non-condensing
Operation: 0 to 85% relative humidity, n on-condensing
Environment
Do not install the device in a site near hea t sources su ch as radiators or air ducts, o r in a place subject to direct sunlight, excessive
dust or humidity. Be aw are that r oom heat rises to the ceiling; check that temperature near the installation site is not excessive.
3.2 Basic Workflow
Before using ClickShare
1. Unpack the ClickShare components and accessories from the box.
For a detailed overview of the content of the ClickShare box,
2. Install the Base Unit in the meeting room using one of the 2 possible installation methods.
For more information on the installing procedures,
3. Connect the Base unit to t he mains power or insert a LAN Ethernet connection that supports Power over Ethernet.
For more information "Power connec tion", page 20,
4. Connect the video signal between the B ase Unit and the dis
play.
5. Connect the audio from the Base Unit to the meeting r oom’s sound system (only required for audio via jack).
6. If configuration via a network is needed, connect a network cable between the Base U nit and the local network (if not y et done
to po wer the Base unit).
7. If desired, configure ClickS hare via the Web Interface.
For more information on the different ways to configure ClickShare,
For more information on u sing ClickSh are, refer to the C lickShare U ser Guide (R5900 014). This manual can
be found on Barco’s website w
ww.barco.com/clickshare Click on Visit the ClickShare product page and go to
tab Downloads..
R5900014 CLICKSHARE 16/09/2013 15
