2. ClickShare Specifications
USB connector
Using the US B connector the Button can be plugged into a laptop (for sharing your screen) or the B ase Unit (for pairing the Button
to the Base U nit or updating its software).
Button
Click the B utton to display the content of the laptop’s screen on the m eeting room display. Clicking the B utton during the meeting
will toggle the sharing of the screen.
LED ring
The LED ring indicates the current status of your ClickShare.
LEDs behavior Explanation
white blinking
• the B utton is plugged in the laptop and initializing or waiting for the user
to start the ClickShare application.
• pairing/software update of the B utton in the Base Unit is in progress.
static white
• ClickShare is ready to start sharing your screen.
• pairing is done. You can now unplug the B utton from the Base Unit.
static re d
• sharing your s creen with the display.
• pairing and software update is done. You can now unplug the Button
from the Base Unit.
red blinking
• an error o ccurred.
off (no light)
• the Button is not or not properly inserted into the USB port.
• the Button might be defective.
• the USB port or computer m ight be defective.
Button label
The label at the bottom of th e B utton contains:
• the Barco logo
• the Barco part number
• the serial num ber
• the revision num ber
• markings for applicable standards
• markings for was te r egulation
• “Made in...”
Handle the Button cable w ith care. Rough handling might cause defects.
2.5 ClickShare App
Introduction
The ClickShare App is freely available from the Apple store. It allows one to display static content s uch as PDF and
JPG documents on iOS devices (mini. required iOS5).
The App is like a virtual Button. Content from tablet devices running the App is treated by the Base Unit just like content coming
from a phys ical Button. Although the App does
not provide an exact real-time mirrorin g of the client device’s screen like the Button
(which is not possible for technical and legal reasons), it is a bit better than pure static content in the sense that also zooming in
and ou t using the pinch ge sture and annotating using a virtual pen are possible. The App also has a shot-and-show capability. This
means that while the App is running in the b
ackground, a picture taken with t he built-in c amera or a snapshot taken using the two
button gesture will automatically be sent to the Base Unit.
10
R5900014 CLICKSHARE 16/09/2013
