Instruction handbook b maXX (BM4-F-)AIO-XX (Analog IO module)
Document No.: 5.01045.08
3TECHNICAL DATA
3.1 Electrical data
1)
The analog outputs can be changed from „fast output“ to „slow output“ and vice versa by the operation soft-
ware.
(BM4-F-)AIO-
01 02 03 04
Number of inputs 2
Number of IO-input links 2
Resolution 10 bit / 12 bit 16 bit 12 bit 16 bit
Design differential input circuit
Input resistance ca. 50 kΩ ca. 100 Ω
Max. input current 200 µA 20 mA
Min. input current - 4 mA
Sample rate inputs, one input used 125 µs
Sample rate inputs, both inputs used 250 µs
Max. analog input voltage - 10 V to + 10 V 2 V
Number of outputs 2
1)
Number of IO-output links 2
Max. output current 1 mA
Resolution 8 bit 16 bit 12 bit 16 bit
Update-rate fast outputs 125 µs
Update-rate slow outputs 8 ms
Short-circuit protection output limited short-circuit protection (max. 10 s)
Analog output voltage - 10 V to + 10 V
