Design and Operation
Instruction handbook b maXX (BM4-F-)AIO-XX (Analog IO module)
Document No.: 5.01045.08
27
of 82
4
4.3 AIO-XX in ES controller
The AIO-XX is mounted stationary in the ES controller.
Figure 4: AIO-XX for ES controller
The controller is ordered with the desired function/option modules, these are mounted
stationary (exception slot H) and cannot be changed. Only the option module in slot H can
be changed/added.
e.g.
AIO-02
position C
AIO-01
always
position E
