4.2.3 Type code BM4-F-AIO-XX for standard controller
Type code:
4.2.4 Danger areas BM4-F-AIO-XX for standard controller
The BM4-O-AIO-XX can be operated in combination with BM4000, only. Please note all
safety notes of the basic unit b
maXX BM4000.
NOTE!
This type code is valid for the BM4-F-AIO-XX of series b maXX 4000 exclusively. For
other plug-in modules different type codes are available.
BM4 - F - AIO - XX - YY Device family, in which the plug-in module can be built in
BM4 - F - AIO - XX - YY Type of plug-in module (function module)
BM4 - F - AIO - XX - YY Name of plug-in module (Analog IO module)
BM4 - F - AIO - XX - YY Version plug-in module (No. of inputs/outputs)
01: 2 x 10 bit input, 2 x 8 bit output
02: 2 x 16 bit input, 2 x 16 bit output
03: 2 x 12 bit input, 2 x 12 bit output
04: 2 x 16 bit input 4 mA...20 mA, 2 x 16 bit output -10 V...+10 V
BM4 - F - AIO - 03 - YY Version hardware (AIO-03 only)
00: For BM4000 without Ethernet interface (BM44XX-XXX-XX2XX-03)
01: For all BM4000 - with Ethernet interface, too
(BM44XX-XXX-XX3XX-03)
NOTE!
Please use in case of b maXX controller with Ethernet interface (type BM4XXX-XXX-
XX
3XX-03) only AIO-03 modules with type code BM4-F-AIO-03-01 and higher.
