Baumuller b maXX BM4 Series Instruction Handbook

33
of 82
Instruction handbook b maXX (BM4-F-)AIO-XX (Analog IO module)
Document No.: 5.01045.08
6MOUNTING
In this chapter we describe the mechanical mounting of the plug-in module
BM4-F-AIO-XX for BM4400, BM4600, BM4700 with standard controller.
6.1 Preparation of mounting
h Check the marking AIO-XX, whether the right plug-in module is available.
Figure 5: BM4-F-AIO-XX for standard controller
h Determine the suitable slot
(see ZSlots BM4-F-AIO-XX for standard controller– on page 23).
NOTE!
The AIO-XX modules are mounted stationary in the BM4400, BM4600, BM4700 with
ES controller and cannot be changed, therefore no mounting is necessary!
