Requirements on the electrical connection
Instruction handbook b maXX (BM4-F-)AIO-XX (Analog IO module)
Document No.: 5.01045.08 Baumüller Nürnberg GmbH
38
of 82
7.2
7.2 Requirements on the electrical connection
7.3 Requirements for the connection cables
Following cables are authorized for use by Baumüller:
m Copper cable, screened with cross-section of min. 0,25 mm
2
, screen connected on
both sides
NOTICE!
The danger is: Electricity.
In case you do not ensure the requirements to the electrical connection of the
Analog IO module, it can be damaged/destroyed.
m Ensure that the electrical power connection parameters as specified in the techni-
cal data are adhered to and that the connections are made in accordance with the
instructions.
m Avoid short circuit between input points and output points. In the event of a short
circuit between input points and output points the Analog IO module may get de
-
stroyed.
NOTE!
Pay attention to EMC compatible cabling, see instruction handbook b maXX
BM4400, BM4400 ES, BM4600, BM4600 ES, BM4700, BM4700 ES (5.12008), chap
-
ter Installation requirements with regard to EMC.
Min. cross section Type of connection
0,25 mm
2
Sub-D 9-pin female,
metal or metallized
