Instruction handbook b maXX (BM4-F-)AIO-XX (Analog IO module)
Document No.: 5.01045.08
8COMMISSIONING/OPERATION
This commissioning assures, that the Analog IO module has been correctly recognized.
Further information relating to commissioning and parameter settings of the encoder
module can be found in parameter manual b
maXX 4000 5.03039.
Assure that before commissioning the following preconditions are fulfilled:
1 The BM4-F-AIO-XX is correctly mounted (standard controller only).
2 The Analog IO module is correctly mounted at the motor.
m The analog IOs must be correctly cabled.
m The connection must be suitable to the electrical specification of the Analog IO
module.
3 The switching cabinet is properly closed and all safety devices are put into operation
4 The b maXX 4000 is ready-for-use.
8.1 Safety notes
Basics
WARNING!
Risk of injury due to improper operation!
Improper operation can lead to severe personal injury or material damage.
Therefore:
m Perform all operational steps according to the details of these instruction hand-
book.
m Before beginning any work, ensure that all coverings and protective devices are
installed and are functioning properly.
m The control cabinet in which the device is installed should be protected against
contact with electrically live parts.
Keep all doors of the control cabinet closed during operation.
