Baumuller b maXX BM4 Series Instruction Handbook

Commissioning/Operation
Instruction handbook b maXX (BM4-F-)AIO-XX (Analog IO module)
Document No.: 5.01045.08
49
of 82
8
8.2.2 Testing of the Analog IO module
Once the plug-in module has been recognized properly, then it can be checked whether
the input and outputs are working correctly using ProDrive.
Pre-conditions Basic unit b maXX BM4000 has been commissioned,
BM4-F-AIO-XX has been plugged in or AIO-XX is available (ES controller).
Analog connections are available/connected and ready for use (pin assignment see
ZConnection diagrams– on page 39), in addition:
m AIO-01, AIO-02, AIO-03
Voltage range of +/-10 V
DC
can be set by a potentiometer.
m AIO-04
Current range of 0 ... 20 mA can be set by a current calibrator
Motor for speed set (clockwise or counter-clockwise) has been connected; shaft ends are
rotating freely.
h ProDrive Navigation „Diagnosis“, submenu „Service“.
h Check in the menu „Service“, whether the Analog-IO-Module has been correctly rec-
ognized, e.g. in the line for the slot D
NOTICE!
Notice electrostatic discharge
The BM4-F-AIO-XX or the b maXX BM4000 may get damaged if the module is
plugged or pulled out when the b
maXX BM4000 is energized.
If the plug-in module has still to be pulled out from the b maXX BM4000 due to an
external action, switch off the b
maXX BM4000.
Try then to push in the Analog IO module again as described in the chapter ZMount-
ing– from page 33 and ZInstallation– from page 37.
Restart the b maXX BM4000 again and check for errors/error messages.
