Instruction handbook b maXX (BM4-F-)AIO-XX (Analog IO module)
Document No.: 5.01045.08
29
of 82
4
4.3.2 Type plate AIO-XX in ES controller
The type code of the AIO-XX is included in the type plate of the basic unit.
4.3.3 Type code AIO-XX in ES controller
The type code has the form:
BM4XXX - XXX - XXXXX[Ryy] - [XXXXXXXX] - [XXX] - XX.
Directly behind the type code is the version code
(- XXXX - X - XXX - XXX).
A module AIO-01 is available in position E, always.
Only the shown section is valid for the AIO-02/03/04 in ES controller.
4.4 Display and operation elements
The encoder module provides neither operation nor display elements.
The LED H4 of the basic unit b maXX BM4000 respectively the emulation of the LED in
ProDrive displays all device errors, including the errors generated concerning the Analog
IO module.
NOTE!
Only 2 analog outputs can be parametrized or linked even more than one AIO module
is available.
BM4XXX - XXX - XXXXX[Ryy] - [XXXXXX] - [XXX] - XX
Device generation
BM4XXX - XXX - XXXXX[Ryy] - [XXXXXX] - [XXX] - XX
ES controller function module, position A
BM4XXX - XXX - XXXXX[Ryy] - [XXXXXX] - [XXX] - XX
ES controller function module, position B
BM4XXX - XXX - XXXXX[Ryy] - [XXXXXX] - [XXX] - XX
ES controller function module, position C
BM4XXX - XXX - XXXXX[Ryy] - [XXXXXX] - [XXX] - XX
ES controller function module, position D
O
P
Q
Analog IO (2 x IN, 2 x OUT), 16 bit see
Analog IO (2 x IN, 2 x OUT), 12 bit see
Analog IO (2x input 16 bit, 4-20mA / see
2x output 16 bit)
AIO-02
AIO-03
AIO-04
