Instruction handbook b maXX (BM4-F-)AIO-XX (Analog IO module)
Document No.: 5.01045.08
25
of 82
4
4.2.2 Type plate BM4-F-AIO-XX for standard controller
The type plate can be found on the connector on the back side of the BM4-F-AIO-XX.
The type code and the serial No. are printed on the type plate.
Figure 3: Type plate BM4-F-AIO-XX for standard controller
NOTE!
Only 2 analog outputs can be parametrized or linked even more than one AIO module
is plugged.
NOTE!
EtherCAT option modules must not be plugged in slot J of a 3-rowed controller unit,
because the module can be damaged.
In case another BM4X-X-XXX plug-in module is plugged in an unsuitable slot, it will
not operate. We have made sure, that neither the module nor the device are dam
-
aged.
Type plate
e.g.
BM4-F-AIO-01
2 analog IN \ 2 analog OUT
S12345678
