Procedure of the commissioning
Instruction handbook b maXX (BM4-F-)AIO-XX (Analog IO module)
Document No.: 5.01045.08 Baumüller Nürnberg GmbH
44
of 82
8.2
8.2 Procedure of the commissioning
The test-commissioning is divided into the following sections:
1 Recognition of the Analog IO module.
2 Function test
8.2.1 Recognition of the Analog IO module
While starting, the control unit reads the identification of the Analog IO module automat-
ically.
After that, check with the help of ProDrive, whether the Analog IO module has been cor-
rectly recognized:
1 Switch on the b maXX BM4000
2 Wait till the system has started
Eliminate any errors / error messages eventually existing in the b maXX BM4000.
These errors might have been caused by faulty assembly (e.g. defective cable) or some
mistake(s) in installation (e.g. supply voltage absent). Only after having corrected the er
-
rors the commissioning can be continued.
NOTICE!
Environmental conditions that do not meet the requirements.
Environmental conditions that are non-compliant can lead to property damage.
Therefore:
m Ensure that the environmental conditions are kept compliant during operation (see
instruction handbook b
maXX 4000, operation conditions).
WARNING!
Risk of injury due to insufficient qualifications!
Inevitably, when operating this electrical device, certain parts of this device are ener-
gized with hazardous voltage. Improper handling can lead to significant personal in-
jury and material damage.
Therefore:
m Only qualified personnel may work on this device!
