BBK DV718SI - Page 70

SR
MISC (12)
108 PRST#
InOut
PD,SMT
Power on reset input, active low
107 ICE InOut PD,SMT Microcontroller ICE mode enable
233 XTALO Output 27MHz crystal output
234 XTALI Input 27MHz crystal input
46 USB_VSS USB Ground USB ground pin
47 USBP Analog Inout USB port DPLUS analog pin
48 USBM Analog Inout USB port DMINUS analog pin
49 USB_VDD3 Analog Inout USB Power pin 3.3V
201 GPIO3 InOut Pull-Down GPIO
200 GPIO4 InOut Pull-Down GPIO
199 RCLKB GPIO5 InOut Pull-Down GPIO
198 RVREF GPIO6 InOut Pull-Down GPIO
Dram Interface (58) (Sorted by position)
176 C_0
IO_0(RD1
6)
InOut Non-pull
1) Digital Video output C bit 0
2) GPIO
175 C_1
IO_1(RD1
7)
InOut Non-pull
1) Digital Video output C bit 1
2) GPIO
173 C_2
IO_2(RD1
8)
InOut Non-pull
1) Digital Video output C bit 2
2) GPIO
172 C_3
IO_3(RD1
9)
InOut Non-pull
1) Digital Video output C bit 3
2) GPIO
171 C_4
IO_4(RD2
0)
InOut Non-pull
1) Digital Video output C bit 4
2) GPIO
169 C_5
IO_5(RD2
1)
InOut Non-pull
1) Digital Video output C bit 5
2) GPIO
168 C_6
IO_6(RD2
2)
InOut Non-pull
1) Digital Video output C bit 6
2) GPIO
167 C_7
IO_7(RD2
3)
InOut Non-pull
1) Digital Video output C bit 7
2) GPIO
177 IO_17 (DQM2)
InOut Pull- Up GPIO
166 YUVCLK
IO_8(DQ
M3)
InOut Pull- Up
1) Digital Video output Clock
2) GPIO
- 66 -
