133 RWE# output DRAM Write enable, active low
132 DQM1 InOut Data mask 1
130 IO_18 (DQS1) InOut Non-pull GIPIO
129 RD8 InOut DRAM data 8
128 RD9 InOut DRAM data 9
127 RD10 InOut DRAM data 10
126 RD11 InOut DRAM data 11
125 RD12 InOut DRAM data 12
124 RD13 InOut DRAM data 13
123 RD14 InOut DRAM data 14
125 RD15 InOut DRAM data 15
121 RD0 InOut DRAM data 0
120 RD1 InOut DRAM data 1
119 RD2 InOut DRAM data 2
117 RD3 InOut DRAM data 3
116 RD4 InOut DRAM data 4
115 RD5 InOut DRAM data 5
114 RD6 InOut DRAM data 6
113 RD7 InOut DRAM data 7
112 IO_19 (DQS0) InOut GPIO
111 DQM0 InOut Non-pull Data mask 0
JTAG Interface( 4 )
51 TDI V_ADIN4
InOut Non-pull
1) Serial interface port 3 data-out
2) Version AD input port 4
3) GPIO
52 TMS V_ADIN5
InOut Non-pull
1) Serial interface port 3 data-out
2) Version AD input port 5
3) GPIO
53 TCK V_ADIN6
InOut Non-pull
1) Serial interface port 3 data-out
2) Version AD input port 6
3) GPIO
54 TDO V_ADIN7
InOut Non-pull
1) Serial interface port 3 data-out
2) Version AD input port 7
3) GPIO
