59 AVSS GND Analog Ground
60 SWING AI HDMI output swing adjustment
61 AVDD VDD Power of DAC, 3.3V
62 VREF A Voltage reference of DAC
63 FS A DAC full scale adjustment
64 AVSS GND Ground of DAC
65 AVDD VDD Power of DAC, 3.3V
66 AVSS GND Ground of DAC
67 AVDD VDD Power of DAC, 3.3V
68 G AO Component analog video output Y/Green
69 AVSS GND Ground of DAC
70 B AO Component analog video output Cb/Blue
71 R AO Component analog video output Cr/Red
72 SPDIF I
Normal : S/PDIF audio input
SCAN mode : test _se input
VDAC test : VDAC test reset, active low
BIST mode : BIST reset, active low.
73 AD3 I Normal : I2S data of channel 6/7
VDAC test VDAC test data bit 11 input
74 AD2 I
Normal : I2S data of channel 4/5
VDAC test : VDAC test data bit 10 input
BIST mode : BIST reset active low
75 AD1 I
Normal: I2S data of channel 2/3
VDAC test VDAC test Data bit 9 input
BIST mode : BIST verify pulse
76 AD0 I
Normal : I2S data of channel 0/1
VDAC test : VDAC test data bit 8 input
BIST mode : BIST write pulse
77 ACK I Normal : S/PDIF clock
VDAC test : VDAC test reset, active high.
78 ABCK I I2S bit clock
79 ALRCK I I2S Left/Right channel flag
80 DVDD18 VDD Power of digital core 1.8V
