34 MSCK/GPO5 O BIST mode : SRAM fail output
Normal : General purpose output
35
MSD/GPO6
IO,PU
MasterI2C on : Master serial interface data input output
BIST mode : SRAM fail output
Normal : General purpose output
36 GPO7 IO,PD Power ON : EPROM word-address type 1 : 16bit , 0 : 8bit
BIST mode : SRAM fail output
Normal : General purpose output
37
GPIO8
IO
BIST mode : SRAM fail Output
Normal : General purpose output / HDMI test Input /
down mixed audio input
38
GPIO9
IO
BIST mode : SRAM fail output
Normal : General purpose output / V - sync in out HDMI test Input
VDAC test : PLL test Enable
39
GPIO10
O
BIST mode SRAM fail output
Normal : General purpose output H-sync in out / HDMI test input
VDAC test : PLL test calibration
40 HTPLG I,PD HDMI Hot-Plug detection
41 AVSS GND Analog ground
42 PLLC0 A PLL Capacitor ground
43 PLLC1 A PLL Capacitor
44 AVDD VDD Analog power, 3.3V
45 AVDD VDD Analog power, 3.3V
46 AVSS GND Analog Ground
47 AVSS GND Analog Ground
48 TCK- AO HDMI Tx clock
49 TCK + AO HDMI Tx clock
50 AVDD VDD Analog power, 3.3V
51 TX0- AO HDMI Tx channel 0
52 TX0+ AO HDMI Tx channel 0
53 AVSS GND Analog Ground
54 TX1- AO HDMI Tx channel 1
55 TX1+ AO HDMI Tx channel 1
56 AVDD VDD Analog power 3.3V
57 TX2- AO HDMI Tx channel 2
58 TX2+ AO HDMI Tx channel 2
