Mounting and wiring
EL70x1
65
Version: 4.4
Connection (right-hand section of the housing)
Terminal point
Name
Signal
1'
A1
Motor winding A
2'
B1
Motor winding B
3'
Sense A
reserved, no connection permitted
4'
Motor supply
+50V
Supply for output stages (maximum +50V
DC
)
5'
A2
Motor winding A
6'
B2
Motor winding B
7'
Sense B
reserved, no connection permitted
8'
Motor supply
0V
Supply for output stages (0V
DC
)
64
66
