Device operation
37
isoRW425_D00052_03_M_XXEN / 02.2017
5.4.3 Fault memory configuration
FAC = Factory setting; Cs = User settings
5.4.4 Interface configuration
FAC = Factory setting; Cs = User settings
( ) = User setting that is not modified by FAC.
Display FAC Cs Description
M OFF Memory function for alarm messages (fault memory)
Display Setting value Description
Range FAC Cs
Adr 0 / 3 … 90 3 ( )
Bus-
Adr.
Adr = 0 deactivates BMS as
well as Modbus and
activates isoData with con-
tinuous data output
(115k2, 8E1)
Adr 1 --- / “---“ ( )
Baud
rate
“---“ : BMS bus (9k6, 7E1)
“1,2k“ … “115k“ -->
Modbus (variable, var.)
Adr 2
8E1
8o1
8n1
8E1 ( )
ModBus
8E1 - 8 data bits
even parity, 1 stop bit
8o1 - 8 data bits
odd parity, 1 stop bit
8n1 - 8 data bits
no parity, 1 stop bit
