Page #25 background imageLoading...
Page #25 background image
25
isoRW425_D00052_03_M_XXEN / 02.2017
4. Installation, connection and commissioning
4.1 Installation
 DIN rail mounting:
Snap the mounting clip at the rear of the device onto the DIN rail so
that it sits securely or
 Screw fixing:
Use a tool to position the rear mounting clips so that they project
beyond the enclosure (a second mounting clip is required, see ordering
information). Fix the device with two M4 screws, see the following
sketch.
The dimension diagram, sketch for screw mounting and push-wire terminal
connection are shown on the following page.
Risk of electric shock!
Touching uninsulated live conductors can result in death or
serious injury. Therefore avoid any physical contact with
active conductors and ensure compliance with the
regulations for working on electrical installations.
If the ISOMETER® is used in rail vehicles, it must be ensured
that the ISOMETER® is installed within a control cabinet that
complies with the fire protection requirements of the
DIN EN 45545-2.
DANGER
